MAYOR V3 Aluminum

MAYOR V3 Aluminum

Our incumbent Mayor has been significantly redesigned for its next campaign. The best value in the category just got better, with new hydro-formed 6061 tubing and new custom RSD carbon fork. Rear stays have been massively beefed-up to increase lateral rigidity and handle the loads that you’ll be applying in a full term of fat fun.

Our flagship fat bike has gotten wider where it counts – 197mm rear thru-axle and 150mm front spacing – so it’ll take any suspension fork or tire swap you’d want.

But with the same proven build, bolstered by RaceFace Cinch cranks and direct-mount 28T ring, and Sun Ringlé 80mm Mulfüt wheels, all rolling on massive Maxxis Minion 4.8” tires, we don’t think there’s anything you’ll need to change to make one successful run after another.

Re-elect the Mayor in 2018. A Fatty you can believe in.

1×10 Carbon Fork

  • Frame: FAT Bike Custom Hydroform AL6061
  • Fork: RSD Custom 490mm Carbon w/15x150mm Axle 51mm Offset
  • Headset: Cane Creek ZS-44
  • Handle Bar: Race Face Turbine 35 760mm
  • Stem: Race Face Turbine Basic 70mm
  • Grips: Ergon GE10
  • Front Wheel: Sun Ringle Mulefüt Fat 26x80mm Front 15x150mm
  • Rear Wheel: Sun Ringle Mulefüt Fat 26x80mm Rear 12x197mm
  • Crank: Race Face 175mm CINCH DM
  • Chain Ring: Race Face 28T NW Ring
  • BB: Race Face 100mm BSA
  • Chain: KMC X10L-CP
  • Cassette: SRAM PG-1020 11/36T 10spd
  • Rear Shifter: SRAM X7 10spd
  • Rear Derailleur: SRAM X7 Type 2 10spd
  • Brakes: Avid BB7 Grey w/FR5 Lever
  • Rotors: Avid 180mm CenterLine
  • Saddle: WTB Volt Comp
  • Seat Post: Race Face Ride
  • Rear Axle: SRAM Maxle Ultimate 12x197mm
  • Tires: Maxxis Minion 4.8

Frame Weight (M): 5 Lbs 10 oz

Sizes: Sm, Med, Lrg & Xlrg

Finish: Orange, Raw, Neon Green or Black

Pricing:
Complete: $1699.00 CAD / $1499.00 USD
Frame / RSD Carbon Fork Combo: $899.00 CAD / $749.00 USD
Frame Only: $599.00 CAD / $499.00 USD
RSD Carbon Fork: $399.00 CAD / $349.00 USD

Included with the Frame Only option:

  • Cane Creek ZS-44 Headset for tapered steer tube – NOT INCLUDED when Frame is on Clearance
  • SRAM Rear Maxle Lite 12x197mm
  • Seat post clamp

All prices listed are Minimum Suggested Retail

1×11 Carbon Fork

  • Frame: FAT Bike Custom Hydroform AL6061
  • Fork: RSD Custom 490mm Carbon w/15x150mm Axle 51mm Offset
  • Headset: Cane Creek ZS-44
  • Handle Bar: Race Face Turbine 35 760mm
  • Stem: Race Face Turbine Basic 70mm
  • Grips: Ergon GE10
  • Front Wheel: Sun Ringle Mulefüt Fat 26x80mm Front 15x150mm
  • Rear Wheel: Sun Ringle Mulefüt Fat 26x80mm Rear 12x197mm
  • Crank: Race Face 175mm CINCH DM
  • Chain Ring: Race Face 28T NW Ring
  • BB: Race Face 100mm BSA
  • Chain: KMC 11-1EPT
  • Cassette: SRAM PG-1130 11/42T 11spd
  • Rear Shifter: SRAM NX 11spd
  • Rear Derailleur: SRAM NX Type 2 11spd
  • Brakes: Avid Level Hydraulic
  • Rotors: Avid 180mm CenterLine
  • Saddle: WTB Volt Comp
  • Seat Post: Race Face Ride
  • Rear Axle: SRAM Maxle Ultimate 12x197mm
  • Tires: Maxxis Minion 4.8

Frame Weight (M): 5 Lbs 10 oz

Sizes: Sm, Med, Lrg & Xlrg

Finish: Orange, Raw, Neon Green or Black

Pricing:
Complete: $2099.00 CAD / $1799.00 USD
Frame / RSD Carbon Fork Combo: $899.00 CAD / $749.00 USD
Frame Only: $599.00 CAD / $499.00 USD
RSD Carbon Fork: $399.00 CAD / $349.00 USD

Included with the Frame Only option:

  • Cane Creek ZS-44 Headset for tapered steer tube – NOT INCLUDED when Frame is on Clearance
  • SRAM Rear Maxle Lite 12x197mm
  • Seat post clamp

All prices are Minimum Suggested Retail

1×11 Mastodon Fork

  • Frame: FAT Bike Custom Hydroform AL6061
  • Fork: Manitou 15x150mm Mastodon EXT Comp 100mm w/Milo Remote Lockout
  • Headset: Cane Creek ZS-44
  • Handle Bar: Race Face Turbine 35 760mm
  • Stem: Race Face Turbine Basic 70mm
  • Grips: Ergon GE10
  • Front Wheel: Sun Ringle Mulefüt Fat 26x80mm Front 15x150mm
  • Rear Wheel: Sun Ringle Mulefüt Fat 26x80mm Rear 12x197mm
  • Crank: Race Face 175mm CINCH DM
  • Chain Ring: Race Face 28T NW Ring
  • BB: Race Face 100mm BSA
  • Chain: KMC 11-1EPT
  • Cassette: SRAM PG-1130 11/42T 11spd
  • Rear Shifter: SRAM NX 11spd
  • Rear Derailleur: SRAM NX Type 2 11spd
  • Brakes: Avid Level Hydraulic
  • Rotors: Avid 180mm CenterLine
  • Saddle: WTB Volt Comp
  • Seat Post: Race Face Ride
  • Rear Axle: SRAM Maxle Ultimate 12x197mm
  • Tires: Maxxis Minion 4.8

Frame Weight (M): 5 Lbs 10 oz

Sizes: Sm, Med, Lrg & Xlrg

Finish: Orange, Raw, Neon Green or Black

Pricing:
Complete: $2499.00 CAD / $2199.00 USD
Frame / Mastodon Fork Combo: $1199.00 CAD / $999.00 USD
Frame Only: $599.00 CAD / $499.00 USD
RSD Carbon Fork: $399.00 CAD / $349.00 USD

Included with the Frame Only option:

  • Cane Creek ZS-44 Headset for tapered steer tube – NOT INCLUDED when Frame is on Clearance
  • SRAM Rear Maxle Lite 12x197mm
  • Seat post clamp

All prices are Minimum Suggested Retail

Frame Specs

  • Handmade Frame: Aluminum 6061 Double Butted and Heat Treated
  • Forged Drop-Out: Aluminum 7000 Series
  • CNC Machined Head Tube: 44mm
  • CNC Machined Bottom Bracket Shell: 100mm BSA
  • CNC Machined Custom Yoke: Aluminum 7000 Series
  • Hardware: Stainless Steel
  • Fork Length: 490mm (100mm)
  • Rear Spacing: 197mm
  • Drop-Out: 12mm Maxle
  • Seat Post Clamp: 34.9mm
  • Seat Post: 30.9mm
  • Max Tire Size: 26×5.05in, 27.5x4in, 29x3in
  • Max Fork Length: 510mm Axle to Crown (120mm Travel)
Size Chart
Diagram
Geometry — Metric
Geometry — Imperial
